PC-P461S 4x100W Super Fast V-mount Charger

›  4-ch simultaneous fast charging

›  Charge both 14.4V and 28.8V V-mount batteries

›  100W/6A for SWIT 14.4V & ≥160Wh batteries

›  100W/3A for SWIT 28.8V & ≥160Wh batteries

›  50W/3A for other batteries

›  3.5-inch color LCD info display

›  Battery cycle times display

›  Top large charging indicators

Features

4x100W Fast Charger for both 14.4V and 28.8V batteries

PC-P461S can charge 4 V-mount batteries simultaneously, support both 14.4V and 28.8V nominal voltage batteries. Super fast charging 100W/6A for 14.4V batteries, and 100W/3A for 28.8V batteries, save up to 60% charging time comparing to normal chargers.
SWIT ≥160Wh batteries support 100W fast charging,
for less capacity or other brand batteries, the charging current will limit to 50W/3A.

Charging Time Comparation

3.5-inch Color LCD Display

PC-P461S provides a 3.5-inch color LCD panel to display charging progress, charging current and voltage.
For batteries with SMBUS info, it will display real time capacity and battery cycle times as well.

Top Charging Indicators

Besides LCD screen info, you can check the charging status at a glance by the 4 large size indicators on the top of the charger.


Red on: 0-80%
Green flashing: 81%-99%
Green on: 100% fully charged
Red flashing: Charging error, check LCD info

Light Weight and Portable

The 4 channel fast charger PC-P461S has minimized the size and weight, and the new handle design makes the charger solid and easy to carry.

Power

Max 450W

Input

AC100V-240V 50/60Hz

Output

DC 16.8V, 6Ax4 (SWIT 14.4V & ≥160Wh batteries)

DC 33.6V, 3A×4 (SWIT 28.8V & ≥160Wh batteries)

DC 16.8V, 3A×4 (Other batteries)

Applicable battery

V-mount battery

Dimensions

330×153×162mm

Net weight

Net 2.43kg; With package 3.3kg
Basic Package

MSRP

MSRP

MSRP

  • PB-H290S

    290Wh Intelligent Bi-voltage Battery Pack

    14.4V/28.8V auto recognition and switching, for Alexa LF and all other normal cameras and chargers, 6A fast charging, 250W high load, 1.5m drop-off proof

    $8222
  • PB-S220S

    220Wh Multi-sockets Square Digital Battery Pack

    Compact designed for Cine-cameras, 4x D-tap, 1x USB, OLED displays remaining time

    $8222
  • S-8113S

    160Wh V-mount Battery Pack

    High Load Li-ion cells with Max 200W, 16A constant output; D-tap DC output, LED power indicators

    $8222
  • S-8180S

    220Wh High Load V-mount Battery Pack

    High Load Li-ion cells with Max 200W, 16A constant output; D-tap DC output, LED power indicators

    $8222
  • PC-P430S

    4-ch V-mount Fast Charger

    3A×4 fast charging current; AC-DC adapter output, LED charging indicators

    $8222
  • S-3812S

    2-ch V-mount Super Fast Charger

    2-ch simultaneous charging, Max 6A fast charging, support AC-DC and Battery-DC adaptor output, LCD display working status

    $8222
  • PB-R160S+

    160Wh Heavy Duty IP54 Battery Pack

    200W/16A load, IP54 waterproof, 1.5m drop-off proof, 6A fast charging

  • PB-R290S+

    290Wh Heavy Duty IP54 Battery Pack

    250W/20A load, IP54 waterproof, 1.5m drop-off proof, 6A fast charging

  • S-8183S+

    270Wh High Load V-mount Battery Pack

    High Load Li-ion cells with Max 250W, 20A constant output; D-tap DC output, LED power indicators
