S-8113S 160Wh V-mount Battery Pack

›  Li-ion, 14.4V, 160Wh large capacity

›  At least 150W, 12A constant load

›  D-tap output socket

›  4-level LED power indicator

›  V-mount connection

›  Multiple circuit protections


Features

High-Load Li-ion Cells

Normal Li-ion batteries offer 100W/8A output and suitable for most ENG cameras, but the Cine Cameras such as ALEXA require around 85W high draw which is too heavy for the normal Li-ion batteries: the battery life will be reduced if long time full draw powering. Moreover, if there’re monitor, lighting work together, and total power will be above 100W, and the normal batteries can not draw completely.
Using S-8113S high-load battery, you can get at least 150W/12A constant power output, which can drive more high power cameras, lightings and other equipments easily, and won’t reduce battery life during long time high power output.

160Wh / 11.1Ah High Capacity

Consists of 16pcs 18650 battery cells, and reaches 160Wh/11.1Ah high capacity.
run approx 5 hours for normal 30W ENG cameras.

6A Fast Charging

S-8113S supports 6A fast charging, to save more than 50% charging time, can be charged from 0 to 80% after 1.5 hours, and fully charged within 2.5 hours.

Build-in D-tap DC Output Socket

A D-tap DC output socket is equipped on the top side of S-8113S battery, for DC14.4V (Nominate) connection, such as on-camera lights, monitors, wireless transmitter, etc..
The Max Power from D-tap is 120W, 10A.

4-level LED Power Indicator

On the side of the battery, there’re 4-level LED power indicators to check the battery remaining capacity. You can get a quick view of capacity before using.

无标题文档

Nominal Voltage

14.4V

Capacity

160Wh/11.1Ah

Max output power

150W

Max output current

12A

Mount Type

V-mount

Operation Temperature

0-40°C

Net weight

Approx 0.9kg

Dimensions

165×90×51mm
Basic Package

MSRP

$8222

MSRP

$8222

MSRP

$8222

  • S-8110S

    146Wh V-mount Battery Pack

    Adpot high performance Li-ion battery cells with intelligent safety protection circuit; D-tap output, LED power indicators

    $8222
  • S-8183A

    240Wh High Load Gold Mount Battery Pack

    High Load Li-ion cells with Max 180W, 15A constant output; D-tap DC output, LED power indicators

    $8222
  • S-8113A

    160Wh Gold Mount Battery Pack

    High Load Li-ion cells with Max 150W, 12A constant output; D-tap DC output, LED power indicators

    $8222
  • PC-P430S

    4-ch V-mount Fast Charger

    4-ch simultaneous charging with 3A fast charging current; LED charging indicators

    $8222
  • PC-U130S

    Portable V-mount Battery Charger

    Ultra portable single channel 3A charging, attached to V-mount battery pins

    $8222
  • PC-U130B

    Portable D-tap Socket Fast Charger

    Ultra portable single channel 3A charging via battery D-tap socket

    $8222
  • S-3822S

    2-ch V-mount Fast Charger

    2-ch simultaneous charging, 3A fast charging, Portable, support AC-DC adaptor output

    $8222
  • S-3812S

    2-ch V-mount Super Fast Charger

    2-ch simultaneous charging, Max 6A fast charging, support AC-DC and Battery-DC adaptor output, LCD display working status

    $8222
  • S-7005S

    Gold mount to V-mount battery Adaptor

    Adapt V-mount batteries to Panasonic gold mount cameras; D-tap DC socket

    $8222
  • S-7104

    D-tap to Pole-tap DC Cable

    Pluged into D-tap socket and output DC via 5.5mm pole-tap

    $8222
  • S-7101

    D-tap to 4-pin XLR DC Cable

    Pluged into D-tap socket and output DC via 4-pin XLR connector

    $8222
  • S-7100S

    V-mount to 4-pin XLR DC Cable

    Attached to V-mount battery pins and output DC via 4-pin XLR connector

    $8222
