PB-S220S 220Wh Multi-sockets Square Digital Battery Pack

› Square shape design for Cine-cameras

› At least 200W, 16A constant load

› 4× D-tap output sockets

› 1× USB 5V/2A power output sockets

› 6A super fast charging

› LCD display accurate remaining run time

› Display power info in both SONY & RED

› Multiple circuit protections


Features

Square shape design for Cine-cameras

PB-S series camera batteries are compact designed, shorter than normal V/Gold mount batteries, and match perfectly with most of the Cine-cameras.

220Wh / 15.3Ah Capacity

Consists of 24pcs of high class 18650 battery cells, nominal voltage is 14.4V and reaches 220Wh / 15.3Ah high capacity. Can run approx 7 hours for normal ENG cameras and approx 2.5 hours for ARRI ALEXA.

High Load for Cine Cameras

At least 200W / 16A load

PB-S220S provides at least 200W/16A high load even at 1% capacity, to drive high power Cine cam- eras and on-camera devices together. The high load cells will also ensure battery life comparing to normal load batteries if long time full load output.

4× D-tap, 1× USB

PB-S220S provides 4x D-tap output sockets with 10A/120W load, and 1x USB 5V/2A socket, to power other on-camera devices together.

6A Fast Charging

Using SWIT S-3812S fast charger

PB-S220S supports 6A fast charging by SWIT S-3812 fast charger, to save more than 50% charging time. The 220Wh PB-S220S battery can be charged from 0 to 80% after 2.3 hours, and fully charged within 3.5 hours.

Digital Power Info

LCD display accurate remaining run time

The build-in LCD can displays remaining power percentage, remaining working time, low power warning, and battery cycle times, and support viewfinder info display on both SONY and RED cameras.

LCD warning codes description

P01 - P13: The battery trigger protection function and it can be recovered;
E01 - E03: Not recoverable error, please contact manufacturers to repair, do not disassemble the battery.
When the battery rests over 10 days or runs out of power, it will enter sleep mode and the LCD will not display.

Common battery protection codes:
P01: Run out of power, please charge the battery asap.
P02: Over-voltage when charging, please remove the battery, discharge the battery to decrease voltage to recover.
P03: Over-current when charging, please remove the battery, and it will recover after 30 seconds.
P05-07: The load is too heavy, please remove the battery, and it will recover after 30 seconds.
P08-09: Battery short circuit, please remover the battery and make sure electrodes are clean, and it will recover after 30 seconds.
P10-13: Temperature protection, please remove the battery and place at room temperature to recover.

Model

PB-S220S

Battery plate

V-mount

Nominal voltage

14.4V

Capacity

220Wh,15.3Ah

Max output

In total: 200W

Electrodes: 200W,16A

USB:10W, 5V/2A
D-tap: 120W / 10A

Dimension

121×95×96mm

Net weight

1.44kg

Max charging current

6A

D-TAP socket number

4

USB socket number

1
Basic Package

MSRP

$8222

MSRP

$8222

MSRP

$8222

  • PC-P430S

    4-ch V-mount Fast Charger

    4-ch simultaneous charging with 3A fast charging current; LED charging indicators

    $8222
  • S-3822S

    2-ch V-mount Fast Charger

    2-ch simultaneous charging, 3A fast charging, Portable, support AC-DC adaptor output

    $8222
  • S-3812S

    2-ch V-mount Super Fast Charger

    2-ch simultaneous charging, Max 6A fast charging, support AC-DC and Battery-DC adaptor output, LCD display working status

    $8222
  • PC-P460S

    4x6A Super Fast V-mount Charger

    4-ch simultaneous charging with 6A super fast charging current; color LCD screen
