› Li-ion battery pack of 7.2V nominal voltage
› 24Wh / 3.3Ah large capacity
› Comparable to SONY NP-F570 battery
› Display remaining power info on camera viewfinder
› Compatible with ARRI Hi-5 hand unit
› Compact size for various camera accessories
› Multiple circuit protections
24Wh of Original Size
S-8570 is an original size replacement battery
for SONY NP-F570, 24Wh/3300mAh capacity,
compatible with cameras and all other video
devices use NP-F style power.
Video Devices Power
S-8570 battery has the thinnest size for
various small video devices. It can power
a camera-top monitor or a wireless
transmitter for nearly 3 hours.
Constant power load: 30W/4A.
ARRI Hi-5 Compatible
With the exactly original size, S-8570 battery
can fit the insert style video devices like ARRI
Hi-5 hand unit, etc. The S-8570 can provide
over 10 hours power to Hi-5.
Charging Compatibility
Like all NP-F style batteries, you can use
SWIT dual channel charger S-3602F to charge
S-8570 batteries. 2x S-8570 can be fully
charged within 1 hour 45 min.
4-way Charging
You can also use SWIT 4-way multi-style mix
charger LC-D421 to charge S-8570 batteries.
4x S-8570 can be fully charged within 1 hour
45 min.
Nominal Voltage | 7.2V |
Capacity | 24Wh, 3.3Ah |
Max output power | 30W, 4A |
Compatible cameras | SONY HVR-Z1/Z5/Z7/V1; DSR-PD150/170/190 |
| SONY NEX-FS100/700/EA50; NXR-M2000/HD1000 | |
| ARRI Hi-5 / Cmotion hand unit | |
Various video gears with NP-F power | |
Dimension | 71×39×21mm |
| Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C(Capacity and Max Load may decrease when operating below 0°) |
Net weight | Net 106g; With package 115g |
MSRP
MSRP
MSRP
1. Warranty Period
We provide 1 year conditional warranty for batteries.
2. Exclusions from Warranty Coverage
The following damages, malfunctions, failures, or safety incidents are not covered under warranty, and SWIT shall bear no liability therefor:
(1) Non-Compliance with User Manual
Operation, maintenance, or storage not in accordance with the instructions set forth in the User Manual; unauthorized disassembly, modification, or repair.
(2) Non-Compliant Charging Equipment and Practices
Use of non-original SWIT chargers or uncertified third-party charging accessories;
(3) Misuse and Physical Damage
Compression, puncture, dropping, impact, collision, water immersion, exposure to high temperatures or direct sunlight, or any other non-normal use not in accordance with the product's intended design.
(4) Use of Damaged or Defective Battery
Continued use of a battery that is damaged, leaking, or exhibiting abnormal overheating without prompt discontinuation.
(5) Natural Capacity Degradation
Reduction in battery capacity resulting from the natural aging process after a certain number of charge/discharge cycles.
(6) Improper Storage and Maintenance
Damage caused by improper storage practices that lead to extended deep discharge or prolonged zero-charge state of the battery.
(7) Force Majeure and Human Factors
Damage caused by irresistible factors (including but not limited to earthquake, fire, or lightning) or human factors.
(8) Non-Quality Defects
Any damage or breakdown not caused by the product's design, workmanship, or manufacturing quality.
(9) Liability Disclaimer
All risks and losses arising from non-compliant use shall be borne entirely by the user.
