› Divide into 2 parts of 92Wh capacity each (Patent)
› Not restricted by IATA air transportation regulations
› Li-ion, 14.4V, 92+92Wh capacity
› D-tap output socket
› 4-level LED power indicator
› Gold mount type connection
› Multiple circuit protections
Large Capacity Battery, IATA Comply
Patented dividable battery design
The IATA DGR regulations restricted the air transportation of over 100Wh Li-ion battery packs. SWIT provides the solution of Dividable Battery to comply with IATA regulations. S-8192A can be divided into 2 parts, and each part contains 92Wh capacity, not restricted by air transportation. And when using S-8192A, just assemble the 2 parts, you can get a Li-ion battery pack of 184Wh large capacity.
184Wh / 12.8Ah High Capacity
When assembled, the S-8192A consists of 20pcs 18650 battery
cells, and reaches 184Wh / 12.8Ah high capacity. S-8192A
can run approx 6 hours for normal 30W ENG cameras, and has no
problem to fly with.
AntonBauer Gold Mount Connection
S-8192A is compatible with AntonBauer Gold mount type power system and we
adopt the high quality connection bolts that ensure the reliable mounting.
Build-in D-tap DC Output Socket
A D-tap DC output socket is equipped on the top side of S-8192A
battery, for DC14.4V (Nominate) connection, such as on-camera
lights, monitors, wireless transmitter, etc.
The Max Power from D-tap is 100W, 8A.
4-level LED Power Indicator
On the side of the battery, there’re 4-level LED power indicators
to check the battery remaining capacity. You can get a quick view
of capacity before using.
Nominal Voltage | 14.4V |
Capacity | 92+92Wh/6.4+6.4Ah |
Max output power | In total:100W |
| Electrodes:100W,8A | |
| D-tap:100W,8A | |
Mount Type | Gold mount |
Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C（Capacity and Max Load may decrease when operating below 0°） |
Net weight | 1.2kg; With package 1.4kg |
Dimensions | 168×101×65mm |
MSRP
$8222
MSRP
MSRP
We provide 2 year conditional warranty, and the following damages/issues are not covered under warranty:
(1) Any damage or breakdown caused by use, maintenance, or storage not according to the User Manual’s instructions, or disassemble, repair without authorization of SWIT.
(2) Battery performance declines, cannot be charged or any charging errors caused by using third-party chargers.
(3) Battery capacity naturally decreased after a certain cycle times of charging and discharging.
(4) The capacity loss caused by over 6-month’s storage, and not charging the battery to re-active it during the period.
(5) Any damage caused by irresistible factors (such as earthquake, fire, lightning etc.) or human factors.
(6) Any damage or breakdown not caused by the product’s design, workmanship, or manufacturing quality, etc.
