◆ Panasonic VBR59/89/118 comparable
◆ For Panasonic AU-EVA1, AG-DVX200
◆ For Panasonic AJ-PX230/270, UPX360
◆ For Panasonic AG-CX350, UX90/180 etc
◆ 7.2V nominal voltage Li-ion battery
◆ 65Wh / 9.02Ah capacity
◆ 30W / 4A constant power load
◆ Built-in 12V reg. D-tap output
◆ Built-in 25W USB-C input and output
◆ 4-level LED power indicator
◆ Multiple circuit protections
65Wh Panasonic VBR59 Battery
with D-tap and USB-C
LB-PD65C is a 65Wh large capacity Panasonic AG-VBR59
compatible battery with regulated 12V D-tap output and
25W USB-C in/out, diversity power for camera top devices.
65Wh Large Capacity
LB-PD65C consists of 6pcs battery cells and has
65Wh/9020mAh large capacity to keep your video
devices powered for longer time. The constant
power load is 30W/4A.
Compatible Panasonic cameras:
AU-EVA1, AG-DVX200, AJ-PX230/270/UPX360
AG-CX350, AG-UX90/180, AG-AC30, etc.
Reg. 12V D-tap Output
The LB-PD65C battery provides a D-tap power output
socket of regulated 12V voltage, widely compatible
with various kinds of video devices.
* The D-tap has 7.2V to 12V (Reg.) conversion and
it’ s not allowed to charge input via this D-tap socket.
USB-C 25W Output
Fast Charging iPhone 12/13
LB-PD65C provides a USB-C sockets, supports
5V 3A, 9V 2.8A, 12V 2.1A, 15V 1.7A, 20V 1.3A,
25W power output to fast charge iphone 12/13
and all kinds of USB-C smart phones or tablets,
with BC1.2, PD2.0/3.0, QC2.0/3.0, FCP, SCP
multiple protocols.
USB-C 25W Charging Input
You can also charge LB-PD65C by USB-C charger.
Supports PD 5V 3A, 9V 2.8A, 12V 2.1A, 15V 1.7A,
20V 1.3A, 25W power input, which means you can
fully charge the 65Wh battery within 3.5 hours.
4-level Power Indicator
Press the power check bottom, the 4-level
LEDs indicates remaining power percentage.
4-way Charging
LB-PD65C can be charged by Panasonic original charger, and SWIT LC-D421 4-way charger you can
charge 4 batteries simultaneously, and fully
charging within 5 hours.
Nominal Voltage | 7.2V |
Capacity | 65Wh, 9.02Ah |
Max power load | 30W, 4A |
D-tap | 12V (reg.) 1.7A, 20W |
USB-C | 25W input: 5V 3A, 9V 2.8A, 12V 2.1A, 15V 1.7A, 20V 1.3A 25W output: 5V 3A, 9V 2.8A, 12V 2.1A, 15V 1.7A, 20V 1.3A BC1.2, QC2.0/3.0, PD2.0/3.0, FCP, SCP |
Original batteries | Panasonic AG-VBR59/89/118G |
Compatible Cameras | Panasonic AU-EVA1, AV-DVX200, AJ-PX230/270 Panasonic AJ-UPX360, AG-CX350, AG-UX90/180, AG-AC30 |
Dimension | 41×70×83mm |
| Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C (Capacity and Max Load may decrease when operating below 0°) |
Net weight | Net 356g; With package0.4kg |
MSRP
MSRP
MSRP
1. Warranty Period
We provide 1 year conditional warranty for batteries.
2. Exclusions from Warranty Coverage
The following damages, malfunctions, failures, or safety incidents are not covered under warranty, and SWIT shall bear no liability therefor:
(1) Non-Compliance with User Manual
Operation, maintenance, or storage not in accordance with the instructions set forth in the User Manual; unauthorized disassembly, modification, or repair.
(2) Non-Compliant Charging Equipment and Practices
Use of non-original SWIT chargers or uncertified third-party charging accessories;
Use of third-party USB-C chargers without compliant PD protocols;
This battery doesn't support charging via D-tap, use any D-tap charger to charge the battery and cause any damage.
(3) Misuse and Physical Damage
Compression, puncture, dropping, impact, collision, water immersion, exposure to high temperatures or direct sunlight, or any other non-normal use not in accordance with the product's intended design.
(4) Use of Damaged or Defective Battery
Continued use of a battery that is damaged, leaking, or exhibiting abnormal overheating without prompt discontinuation.
(5) Natural Capacity Degradation
Reduction in battery capacity resulting from the natural aging process after a certain number of charge/discharge cycles.
(6) Improper Storage and Maintenance
Damage caused by improper storage practices that lead to extended deep discharge or prolonged zero-charge state of the battery.
(7) Force Majeure and Human Factors
Damage caused by irresistible factors (including but not limited to earthquake, fire, or lightning) or human factors.
(8) Non-Quality Defects
Any damage or breakdown not caused by the product's design, workmanship, or manufacturing quality.
(9) Liability Disclaimer
All risks and losses arising from non-compliant use shall be borne entirely by the user.
