› 8-ch simultaneous B-mount fast charging
› DC33.6V, 3A, 100W for ≥160Wh batteries
› DC33.6V, 1.3A, 44W for <160Wh batteries
› 2× 3.5-inch color LCD info display
› Battery cycle times display
› Large LED charging indicators
› Wall mounting or 19-inch rack install
8x100W Ultra Fast Wall Charger
MATRIX-B8 is an 8-ch simultaneous B-mount wall charger with 33.6V 100W ultra fast charging speed each channel, charging SWIT HB-A290B, BIVO series, and compatible with other B-mount batteries that support 33.6V charging voltage like CoreSWX.
Charging Time Chart
Flexible Wall Mounting Plate
MATRIX-B8 provides with a wall mounting plate on the backside, to be screwed onto the wall, or mounting to standard 19-inch rack bracket.
You can even install the mounting plate onto storage
rack or DIT cart.
3.5-inch Color LCD and Indicators
MATRIX-B8 provides 2x 3.5-inch color LCD to display charging progress, charging current, voltage, battery cycle times for each channel.You can also check the charging status by large charging indicators from a distance.
Power | Max 900W |
Input | AC100V-240V 50/60Hz |
Output | DC 33.6V, 3A 100Wx8 (≥160Wh B-mount batteries) DC 33.6V, 1.3A 44W×8 (<160Wh B-mount batteries) |
Applicable battery | B-mount battery |
Dimensions | 630×436×89mm |
Net weight | Net 10.6kg |
