Cine Floor Battery

1600Wh Modular Add-On

Elevate your video production capabilities with the innovative VOLTA Modular Add-On Floor Battery, compact design, massive power, to meet the rigorous demands of professional cinematography. This state-of-the-art battery system is the ultimate solution for powering your cameras, lighting, and a wide array of film equipment on set.

1600Wh per section Add-ON

The VOLTA floor battery allows you to effortlessly stack and install add-on battery pack to expand power capacity. Each battery pack delivers a substantial 1600Wh of energy, ensuring that your equipment has the juice to keep the production rolling without interruption.

Max 8 Layers 12.8kWh Capacity

The system supports a maximum of 8 stacked battery packs, meeting the long-term power supply needs for a variety of high-power cine equipment.

Versatile DC Power Outputs

12V, 24V, 48V, USB-C, 1700W Load

VOLTA-DC Floor Battery Provides:
1× 4-pin XLR DC 15V 10A output
1× 3-pin XLR DC 24V 15A output
1× SpeakON DC 24V 15A output
1× 3-pin XLR DC 48V 15A output
1× SpeakON DC 48V 25A output
1× USB-C 5V/9V/12V/20V 65W output

All output sockets can work simultaneously, and the constant power load is 1700W in total.

ENG / CINE Cameras Power

15V / 24V outputs

The 15V and 24V outputs are industry-standard connectors, compatible with all kinds of CINE camera or ENG camcorders to get infinite power for long-duration shoots and video productions.

Power for Remote Heads

24V output, 360W Load

The 24V output is particularly beneficial for professional cinematography to power the remote heads and cine cameras. Variety of remote head brands are compatible.

Film Cart Power Center

15V / 24V / USB-C outputs

The VOLTA floor battery is designed to be highly adaptable and convenient for use on a film cart, providing centralized power supply to a variety of equipment, including monitors, cameras, wireless video receiver, and laptops, ensuring continuous operation throughout the shooting process.

Live Production Power Center

15V / 24V / USB-C outputs

Exceptionally well-suited for director's desks, offering a centralized power supply solution for video switchers, monitors, computers and live streaming devices. The system supports power output while charging, ensuring uninterrupted power supply for safe live productions.

Power for Cine Lightings

24V / 48V outputs, Max 1200W

The regulated 24V and 48V power outputs are widely compatible high power lighting fixtures, including ARRI Skypanel-X, Skypanel S60 Pro, Skypanel S60/S120, Orbiter, Creamsource Vortex, Aputure LS-600/1200 etc.
Moreover, the DC power supply offers higher efficiency that contributes to greener and more energy-saving practices on set.

LED Power Info Display

Remaining time & Battery Health

The LED screen displays power percentage, remaining run time, and the health level of each battery unit.

XT60 Solar Panel Charging

400W Max, 4.5 hours Fully Charged

The VOLTA floor battery is a green energy solution that supports solar charging, with XT60 interface for compatibility, 12-60V, 400W Max, and can be fully charged in as fast as 4.5 hours, making it an ideal backup for outdoor video productions and emergencies.

Support Discharge while Charging

Uninterrupted Power Supply

VOLTA floor battery has charger built-in, and each 1600Wh battery pack can be fully charged within 6.5 hours. The system supports discharging while charging as well, provides uninterrupted power to your equipments.

-20°C Power Up

The VOLTA floor battery adopts cold-resistant ternary lithium cells and with SWIT's unique low-temperature cold startup process, allows for normal discharge even in extreme cold environments as low as -20°C, perfect for filming in freezing regions, guaranteeing a dependable power source even in the most severe conditions.

Ultra Low Standby Power

Keep Power for 10 Years Storage

The normal batteries need charging every few months, otherwise the battery life will be seriously affected.
While the VOLTA floor batteries will enter sleep mode automatically if there’ s no output for 12 hours, and will keep power more than 10 years of storage, and you don’ t need to periodically charge the storage batteries.

Optional Add-On Battery Unit

Install between the top control box and bottom battery unit, simply by connecting 2× power wires and 1× data wire. 1600Wh each.
Optional purchase SKU: VA1600

Optional DC Cable for Lightings

Provide the following optional DC cables for various light fixtures to get power from VOLTA:
