M-1093F Dual 9-inch FHD Waveform Rack LCD Monitor

› 9-inch IPS LCD Panel ×2

› 1920×1200 resolution, 1000:1 contrast

› 19-inch 4U rack mounting, ±30° rotatable

› 2K/3G/HD/SD-SDI, HDMI, CVBS monitoring

› 16-ch Embedded audio meters with alert

› Select any 2 audio channels to output

› Waveform Y/Cb/Cr/R/G/B and single line

› Vector scope, histogram R/G/B/Y

› AFD, H/V delay, R/G/B/Mono, False color

› TSL UMD and text TALLY display

› Zebra stripes, Peaking focus assist

› SDI timecode display

› Marker 4:3, 13:9, 14:9, 15:9, 1.85:1, 2.35:1

› TALLY light and GPI control

› USB firmware upgrade


Features

9-inch IPS LCD

IPS panel with LED backlight

The M-1093F adopts 2× 9-inch IPS (In-Plane Switching) LCD panels, with Full HD 1920×1200 resolution and LED backlight, 1000:1 contrast. The viewing angle is Horizontal: 170° / Vertical: 170°

Input/Output Interfaces

SDI / HDMI / CVBS / Analog Audio

Each LCD of M-1093F supports:
2K/3G/HD/SD-SDI input × 2
2K/3G/HD/SD-SDI loop output × 2
HDMI 1.3 input × 1
HDMI 1.3 loop output × 1
CVBS input × 1
CVBS loop output × 1
3.5mm analog audio input × 1
3.5mm analog audio output × 1

Video Analysis Assistant Pattern

Waveform / Vector scope / Histogram

M-1093F supports video analysis assistant patterns includes: Waveform (Y/Pb/Pr/R/G/B), Vector scope, Histogram (R/G/B/Y), to convert the digital video quality info (Luma, Color, Saturation, etc) to patterns, and the patterns can be switched on/off individually, select display position (Up/Down/Left/Right), size, color, and translucence.

Embedded audio monitoring

Up to 16-ch meters with alert and select output

M-1093F supports SDI-16ch and HDMI-8ch embedded audio meters display, with marks and audio abnormal alert info. Users can also select any 2 channels audio to output via 3.5mm socket or speakers. The audio meter pattern position can be selected from one of four corners, and you can select to display only 2 channels, 8 channels, and full 16 channels. Also scale markers, alert info, and translucent of the audio meter pattern are selectable.

UMD and Text-Tally Display

TSL 3.1 / 4.0 Protocol

M-1093F supports UMD and Text-Tally display of TSL 3.1/4.0 protocol, with 1-126 TSL address selection, and Max 8 letters displayed. The UMD/TALLY signal inputs via RJ45(RS485) port on the rear panel of the monitor.

Peaking, R/G/B/Mono only, Zebra, False color

Timecode, H/V delay, AFD, Scale Markers

3-color TALLY Light

RJ45(RS485) input signal

There are front TALLY lights of Red, Green and Yellow colors on each screen, and users can define the pins of RJ45 port to control the TALLY lights.

USB Firmware Upgrade

The monitor provides a standard USB port on the rear panel, for firmware upgrade. Users can download the latest firmware file to a USB stick, and directly insert into M-1093F monitor to upgrade, without PC connection.

Power Supply

M-1093F provides a 4-pin XLR socket of DC 6.5-24V power input, for the both 2 screens, and an AC-DC adaptor is attached on the rear panel of the monitor.

Installation

M-1093F is standard 19” rack mount fixing, occupies 4U height. The monitor is ±30° up and down rotatable when installed on racks.

LCD Performance

Size

9 inches ×2

Display area

191.52×119.70mm

Resolution

1920×1200

Aspect ratio

16:9 (4:3 adjustable)

Brightness

450cd/m2

Contrast

1000:1

Color

16.77 million colors

Viewing angle

Horizontal: 170°; Vertical: 170°

Input(Each LCD)

BNC ×2

2K/3G/HD/SD-SDI input×2

BNC ×1

Composite input

HDMI ×1

HDMI input

3.5mm ×1

Analog audio input

Output(Each LCD)

BNC ×2

2K/3G/HD/SD-SDI loop output

BNC ×1

Composite loop output

HDMI ×1

HDMI loop output

3.5mm ×1

SDI, HDMI, Analog audio output

Video Format

SDI

2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)

2048×1080i (60 / 59.94 / 50)
1080p (60 / 59.94 / 50)
1080i (60 / 59.94 / 50)
1080p (30 / 29.97 / 25 / 24 / 23.98)
1080psf (30 / 29.97 / 25 / 24 / 23.98)
720p (60 / 59.94 / 50)
480i (59.94)
576i (50)

HDMI

480i/ 576i / 480p / 576p
1080i (60 / 59.94 / 50)
720p (60 / 59.94 / 50)
1080psf (30 / 29.97 / 25 / 24 / 23.98)
1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)

CVBS

NTSC / PAL

General

Input voltage

DC 6.5V-24V

Power consumption

≤36W

Working temperature

0°C~+40°C

Working humidity

10%~90%

Storage temperature

-15°C~+60°C

Storage humidity

10%~90%

Dimensions

484×177×112.8mm

Net weight (main body)

2.8kg
Basic Package

MSRP

$8222

MSRP

$8222

MSRP

$8222

  • AC-DC Adaptor

  • S-1093F
