› 416pcs ultra bright long-life LEDs
› Surface mounted LED technology
› 120°(half-declined 65°) wide beam angle
› 3200K-6500K continuously adjustable
› 15W power, 550Lux @ 1 meter center
› 0-100% flick-free dimming
› Super high CRI 95, TLCI 97
› Built-in NP-F battery plate
› Provide snap-on diffuser
416pcs SMD-LEDs
Bright and wider beam angle
CL-15 is an 15W bi-color on-camera LED light, with
416pcs ultra bright SMD LEDs, equally spread wider
beam angle, accurate color render and longer life time.
Super wide beam angle
LED 120°; Half-declined at 65°
The SMD LED of CL-15 has 120° wide beam angle,
and generates an equally spread, wider area light
comparing to traditional DIP LED bulbs.
Take center illuminance as 100% brightness, when
declined to 50% at the edge, the "half-declined" beam
angle can still reach to 65°, which means the light is
equally spread onto the whole environment, instead
of just concentrated at center.
Bi-color temperature
3200K-6500K continuously adjustable
CL-15 mixed with 3200K and 6500K SMD-LEDs, and the output color temperature can be continuously adjustable from 3200K to 6500K.
The bi-color SMD LED is more reliable and has better consistency on color temperature.
High Color Reveal Ability
CRI 95; TLCI 97
CRI (Color Rendering Index) is a measure of the ability
of a light source to reveal the colors of various objects
faithfully in comparison with a natural light source.
And TLCI (Television Lighting Consistency Index) is
special for the color reveal ability by camera sensor.
Max value 100.
The normal LED light has 80-85 CRI or TLCI, while
CL-15 offers the super high CRI at 95 and TLCI at 97,
and will not lose the object original colors.
Dimmer/CCT Control
CL-15 provides 0-100% Dimmer knob and
3200-6500K color temperature knob, for
easy adjustment.
Built-in NP-F Battery Plate
CL-15 has built-in an NP-F DV plate, to power by NP-F batteries. Beside the plate the CL-15 provides
4-level battery power indicator to show remaining capacity of the battery.
Diffusing Cover
With organic light diffusion agent
CL-15 provides a diffuser cover, to be attached on
the front of LEDs. The diffuser cover adopts the PC
material with organic light diffusion agent, which
increased the transmission of light, and provides a
soft, glareless and comfortable lighting effect.
LED | 416 pcs SMD LEDs |
Illuminance | 550Lux @ 1 meter |
Beam Angle | LED 120°; Half decline at 65° |
Color temperature | 3200K ～ 6500K |
Color render | CRI 95; TLCI 97 |
Working voltage | DC 7.2V～8.4V, NP-F battery only |
Power consumption | Approx. 15W |
Dimensions | 174(W)×92(H)×19(D)mm |
weight | Net 145g; With package 0.2kg |
