› 7.2V Li-ion battery pack
› For JVC HM600/650, LS300
(GY-HM250 Not compatible)
› Display remaining power info on camera viewfinder
› 47Wh / 6.6Ah capacity
› 4-level LED power indicator
› 7.2V Pole-tap DC output
› 5V/1A USB charging output
› Multiple circuit protections
JVC HM600/LS300 Compatible
Similar battery as SSL-JVC50, Display power info
S-8i50 is the replacement battery for SSL-JVC50, compatible with JVC
Camcorder HM600/650, LS300 and HMQ10. S-8i50 can exchange digital
info with the JVC cameras, and display remaining power info on the
camera viewfinder.
47Wh / 6.6Ah High Capacity
With 7.2V nominal voltage, the S-8i50 has 47Wh / 6.6Ah capacity, higher than the
original battery SSL-JVC50, and can run approx 4 hours on JVC GY-HM650 camcorder
when LCD monitor is on.
Build-in Pole-tap DC Output Socket
A 5.5/2.1mm pole-tap DC output socket is equipped on the side of S-8i50 battery, for DC
7.2V (Nominate) connection. You can connect on-camera LED light, monitor or wireless
transmitter on the pole-tap socket, and get power simultaneously with camera.
The Max power from the pole-tap is 40W, 5.5A.
Build-in 5V/1A USB
Use S-8i50 as Power Station to your cell phone!
It’s rather a fantastic function to have a USB socket
on the DV battery! Connect your smart phone or
pad to the USB socket, press the “Check” button,
and then the S-8i50 starts to output 5V/1A power
to charge your devices!
4-level LED Power Indicator
The S-8i50 battery has the 4-level LED power indicators to check the
battery remaining capacity. You can get a quick view of capacity
before using.
The “Check” button can also be used to trigger USB charging.
Easy Charging
The S-8i50 can be charged on SWIT Dual channel charger S-3602i or 4-ch charger LC-D421. It takes about 4 hours and 30 minutes to charge from empty to 100%.
Nominal Voltage | 7.2V |
Capacity | 47Wh, 6.6Ah |
Max output power | Total: 40W, 5.5A |
Pins: 25W,3.5A | |
| D-tap: 30W, 4A | |
| USB: 5W (5V / 1A) | |
Compatible cameras | JVC GY-HM600/650, LS300, HMQ10 |
Dimension | 76×70×43mm |
| Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C（Capacity and Max Load may decrease when operating below 0°） |
Net weight | Net 313g; With package0.35kg |
MSRP
MSRP
MSRP
We provide 1 year conditional warranty, and the following damages/issues are not covered under warranty:
(1) Any damage or breakdown caused by use, maintenance, or storage not according to the User Manual’s instructions, or disassemble, repair without authorization of SWIT.
(2) Battery performance declines, cannot be charged or any charging errors caused by using third-party chargers.
(3) Battery capacity naturally decreased after a certain cycle times of charging and discharging.
(4) The capacity loss caused by over 6-month’s storage, and not charging the battery to re-active it during the period.
(5) Any damage caused by irresistible factors (such as earthquake, fire, lightning etc.) or human factors.
(6) Any damage or breakdown not caused by the product’s design, workmanship, or manufacturing quality, etc.
